Fin Fan Air Coolers-Power Plant-Oil And Gas
- Leave Your Message
Air Cooled Heat Exchanger / Air Fin Cooler / Fin Fan Cooler
Air Cooled heat exchangers are usually utilized when cooling water source is limited or expensive. It acts as a heat transfer equipment in which ambient air comes in contact with fins within the tubes containing hot fluid.
This heat exchanger type is available as forced or induced draft and it can be custom designed to suit different industry applications.
Datang Fin Tube Industrial Air Cooled Heat Exchanger For Air To Air
General Description
Industrial Air Cooled Heat Exchanger For Air To Air is a heat exchanger with fin tubes, and it can direct cool the medium by air without water.
And forced draft & induced draft are the most common ventilation types.
Finned tube bundle, screw tube header, louver and fan are main parts.
TECHNICAL SPECIFICATIONS
|
Part Models
|
Tubes QTY
|
Pressure
(MPa) |
Tube bank
QTY |
Bare tube heat transfer area(m2)
|
Finned tube heat transfer area(m2)
|
|
GP12x3-4-172-1.6S-23.4/L(DR)-Ia
|
182
|
1.6
|
4 |
172
|
4025
|
|
GP12x3-4-172-2.5S-23.4/L(DR)-Ia
|
2.5
|
||||
|
GP12x3-4-172-4.0S-23.4/L(DR)-Ia
|
4.0
|
||||
|
GP12x3-8-344-4.0S-23.4/L(DR)-Ia
|
364
|
4.0
|
8
|
344
|
8050
|
|
GP9x2-6-126-1.6S-23.4/L(DR)-Ia
|
177
|
1.6
|
6
|
126
|
2948
|
|
GP6x1-8-52.2-4.0S-23.4/L(DR)-Ia
|
108
|
4.0
|
8
|
52.2
|
1221
|
The main benefit of the Fin Fan Air Coolers is the elimination of an auxiliary water supply ( water lost due to evaporation and drift ) making it a “greener” option compared to other heat exchanger types. It also represents lower capital, operational and maintenance costs.
Datang is capable of supplying ASME codes for the materials, design, fabrication, testing and inspection of air-cooled heat exchangers. Fabrication can be done as per drawing or it can be an entirely new design. It is possible to supply the Air cooled heat exchangers with fan and motor or just the bundle.
FAQ
1, Fluid material and percentage(if mixture).
2, Fluid flow rate.
3, Fluid temperature(inlet & outlet)
4, Fluid pressure(inlet)
5, Ambient dry-bulb temperature
6, Installation area(if required)
Customer factory inspection-Datang Fin Tube
