In the world of flower cultivation, the insulation of flower shed is like a protective umbrella for the delicate flowers, and the 1-inch spiral fin tube has become an ideal choice for flower shed insulation with its many advantages.

The 1-inch spiral fin tube has excellent heat dissipation characteristics and can create a suitable temperature environment for the flower shed. Although its 1-inch specification seems small, it has just the right heat medium flow capacity. When the heat medium flows in the tube, it can smoothly transfer heat.

Stainless Steel Finned Tubes for Condensers and Cooling Systems

The design of the spiral fin is even more exquisite. The spiral-shaped fins are like warm tentacles, which greatly increase the heat dissipation area, allowing the heat to spread more fully and evenly to every corner of the flower shed. In the cold season, it can quickly increase the temperature in the flower shed, create a warm and comfortable home for all kinds of flowers, protect the flowers from the harm of low temperature, so that they can grow normally and bloom beautifully. Whether it is a delicate rose or an elegant daisy, they can thrive at a suitable temperature.

In terms of applicability, the humidity in the flower shed is usually high, and there will be certain complex situations such as fertilizer odor.

Most of the 1-inch spiral finned tubes are made of materials with good corrosion resistance, which can easily cope with such an environment, will not be easily corroded and rusted, and have a stable structure, which can provide heat protection for the flower shed for a long time.

It is more flexible in installation, and can be reasonably laid out according to the actual shape and size of the flower shed to ensure that the temperature distribution in the entire flower shed is uniform, and there is no problem of excessive local temperature difference, so that every flower can enjoy uniform warmth.

With its efficient heat dissipation, good adaptability and flexible installation characteristics, the 1-inch spiral finned tube plays an important role in the insulation of the flower shed, guarding the colorful flower shed.

Spiral welded finned tubes for pepper drying equipment

1-Inch Spiral Finned Tubes for Greenhouse Heating Systems

Introduction

Spiral finned tubes with 1-inch (25.4mm) base diameter provide an optimal balance between heat transfer efficiency and space requirements in greenhouse environments. Their design ensures uniform heat distribution while minimizing pressure drop in heating circuits.

Spiral Finned Tube Key Features

Corrosion-resistant construction suitable for humid environments
High heat transfer efficiency with minimal energy consumption
Compact design that maximizes growing space
Low maintenance requirements

1-inch Spiral Fin Tube Technical Specifications

Standard Dimensions

Parameter	Value Range	Unit
Base Tube Diameter	25.4	mm
Fin Height	12–16	mm
Fin Pitch	5–8	mm
Fin Thickness	0.8–1.2	mm
Tube Length	1500–6000	mm

Material Options

Component	Material Options	Temperature Range (°C)
Base Tube	304/316L Stainless Steel	–20 to 300
Fins	Aluminum/Stainless Steel	–20 to 250

Performance Data

Parameter	Typical Value	Unit
Heat Output	150–300	W/m
Water Flow Rate	0.2–0.5	m³/h
Working Pressure	0.6–1.6	MPa
Surface Temperature	40–70	°C

Key Notes:

‌Fin Pitch‌: Distance between adjacent fins affects heat transfer efficiency.
‌Material Compatibility‌: Stainless steel options provide superior corrosion resistance for humid environments.
‌Thermal Output‌: Values correlate with water flow rates and surface temperatures.
