Datang Fin Tube is a leading Titanium Finned Tube manufacturer and supplier.

Titanium Finned Tubes can be divided into argon arc welding tubes and laser welding tubes According to different welding processes. Usually many low finned tube will use argon arc welding to produce. If it has high fin height and small fin pitch, only laser welding is available to produce. The laser welding finned tube has a fully automatic welding process, saving manpower costs; secondly, the laser welding fin is firm, strong, and the test with high tensile strength is qualified. Laser welding is more efficient.

If you want to know more about our Titanium Finned Tube, please feel free to contact us, we will reply you within 24 hours.

Titanium Laser Welded Finned Tube Technical specifications

Tube outside diameter 10.0–150.0 mm
Tube thickness 1.0–5.0 mm
Fin height 0.4–17 mm
Fin thickness 0.4–1.0 mm
Fin pitch 2.0-20 mm
Max. tube lengths 12.0 m

Titanium Laser Welded Finned Tube Features
Thin and continuous ideal seams
Small heat affected area
Slightly discolored welding parts
The tubes and fins have only slight microstructure changes
High heat forms seams
Laser welding is carried out in a protective atmosphere, so the weld is free of impurities
Single-arm rings are marked with rated load.
Finished paint is applied to the surface of the single-arm ring.

Titanium Laser Welded Finned Tube Advantage
1. The laser welding finned tube (finned tube) fin machine has a high degree of automation, and the welding of the fin to the tube and the winding of the tube are synchronized
2. 100% welding rate, laser welding finned tube and fins are strong, the welding strength exceeds 600MPa.
3. The precision of laser welding tube finishing machine is up to 0.05mm
4. 0 contact resistance, achieve high efficiency of heat transfer of spiral finned tube by laser welding.

Packaging of Titanium Finned Tube:
